Gas Volume Analyzer GVA-710

Gas Volume Analyzer GVA-710

The GVA-710 is a dedicated instrument that automatically measures gas volume, internal gas pressure, air content and oxygen concentration for quality control in the bottling process of carbonated drinks.





  • Fully automatic measurement: Ensure safer operation, less workload and consistent result
  • Reduced measurement and preparation time: Reduced time by 30 to 70% as compared to conventional model
  • Support for a variety of samples: Able to measure cans, bottles, and PET bottle ranging from 160 mL to 2000 mL
  • Method function: 20 methods with different sample properties can be registered in the instrument
  • Support for barcode reader: Barcode information such as sample ID affixed on the container can be scanned and transferred using a commercial barcode reader
  • Visibility inside the absorbent cylinder: The dissolution status of carbon dioxide gas and air content in the absorbent cylinder can be visually checked by operators
  • Measurement range: Pressure (0.010 to 0.500 MPaG), Temperature (0 to 50 oC), Residual gas volume (0 to 30 mL) and Oxygen concentration (0 to 21 vol%)
  • Measurement accuracy: Pressure (± 0.001 MPa), Temperature (± 0.05 oC), Residual gas volume (± 2% (for volume 5 mL to 30 mL; ± 0.1 mL (for volume 0 mL to 5 mL), Oxygen concentration (± 0.2 vol%)
  • Measurement time: ­Gas volume/internal gas pressure (Approx. 90 seconds for one sample), Residual gas volume (Approx. 5 to 12 min for one sample)
  • Sample container: Various steel cans, aluminum cans, PET bottles, and glass bottles (160 mL to 2000 mL; Size: height 85 mm to 315 mm, diameter 53 mm to 110 mm)
  • Stored data: 500 latest measurement results; 20 methods
  • External output: RS-232C: 1ch for connection to a printer or a computer, USB port: 1ch for data transfer and barcode reader
